· Electronically encoded with only one ID; online addressing by controller or addressing by encoder; automatic log-in, convenient installation and debugging.

· Able to detect shut-off failures of 24V power supply

· Plug-type design, convenient installation and wiring.

· Working temperature: －10℃ ～ +50 ℃

   · Working humidity: ＜95% RH (No condensation of moisture)

   · Bus working voltage: 24V Pulsating voltage· 24V power supply: DC 24V±¹⁰₁₅%

   · Standby current: ＜0.35mA (bus); ＜1.0mA (DC24V)

   · Operating current: ＜1.5mA (bus); ＜20mA (DC24V)

    Relay contact: Two sets normally-on/off, DC30V/1A; AC120V/1A DC

  · Wiring system: Two-wire bus (non-polarized) DC 24V power supply
